Automatic Wire Crimping Machine High Precision 6 - 12MM Length
Product Details:
| Place of Origin: | Dongguan, China |
| Brand Name: | RZT |
| Certification: | ISO, CE |
| Model Number: | RZT-05A |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Wooden Case |
| Delivery Time: | 15-20 Days |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 50 Sets / Month |
|
Detail Information |
|||
| Wire Range: | 0.5-1.5mm²(AWG20#-16#) | Crimping Length: | 6~12mm |
|---|---|---|---|
| Voltage: | 220V 50HZ | Warranty: | One Year |
| Weight: | 30KG | Dimension: | 560*250*420mm |
| High Light: | hydraulic hose crimping machine,electric crimping machine |
||
Product Description
Automatic Bulk Tube Pre-Insulation Stripping and Crimping Machine
Description:
The RZT-05A provides efficient processing of loose wire end sleeves with plastic collars in different lengths. This machine no special tooling length adjustment. It is simply done by a thumb wheel. The machine features a high level of reliability and flexibility. The use of premium components in combination with a robust construction ensures reliable operation.
Product Features:
1. Vibrating plate for terminal feeding, convenient and fast in changing the terminal.
2. High precision for stripping length & crimping height.
3. The wire inserting part is horn shape which is convenient for wire threading, we adopted imported components and cylinder ensures its stable performance.
4. Wire threading, stripping and crimping are finished at one time, especially for crimping international standard tube terminal. It simplifies the complicated procedure, the overall efficiency is increased by 3-4 times compared to the manual working.
Product Specification:
| Item | Performance |
| Product Name | Bulk Tube Pre-Insulation Stripping and Crimping Machine |
| Brand Name | RZT |
| Model | RZT-05A |
| Function | Wire threading, Stripping and Crimping |
| Wire Size | 0.5-1.5mm²(AWG20#-16#) |
| Cycle Time | Approx 1.3 Second |
| Crimping Length | 6~12mm |
| Feed Length | 27mm+Crimping Length |
| Air Supply | 0.5~0.7MPa |
| Power | 220V/50HZ |
| Dimension | 560*250*420mm |
| Weight | 30KG |
